A semi-modular analog synthesizer that makes modular synth more accessible and understandable than ever before.

Creating new sounds that do not exist in the outside world has been an enduring dream since the birth of electronic musical instruments. This dream has progressed and expanded throughout the development of new and unique musical devices.

The popularity of modular synthesizers around the world has brought new excitement and interest in "West Coast style" synthesis that deviates from traditional synth norms.

This series design's compact body packs eight modules and 50 patch points. While learning the basics of a modular synth, you can use the popular features of the volca synthesizer series to control a unique and different flavor of analog sounds.

Technical Specifications

Keyboard

Multi-touch Keyboard / Step key

Synthesizer

Type

Analog synthesis

Maximum Polyphony

1

Its structure

2 VCO (Triangle), 2 EG, 2 LPG, digital effect

Sequencer

Number of parts

1

Number of steps

16 (pattern chaining available)

Number of patterns that can be saved

16

Links

Audio output

Headphone (3.5mm stereo mini jack)

Synchronize

Sync In (3.5mm monaural mini jack, Maximum input level: 20V
Sync Out (3.5mm monaural mini jack, Maximum output level: 5V)

Control In

CV-IN jack (TRS mini phone jack)

Strength

Battery life

Approximately 10 hours (with alkaline batteries)

Power supply

AA alkaline battery ×6, AA nickel-metal hydride battery ×6 or AC adapter “KA-350” (optional)

Other

What is included in the

AA alkaline battery ×6 (for control), Sync cable, Pin cable for patch 1 set, Module reference sheet

Accessories (sold separately)

SEQUENZ CB-4VOLCA hard case, SEQUENZ CC-VOLCA soft case, SQ-CABLE-6 sync cable

Dimensions (W x D x H)

193 × 115 × 39 mm / 7.61 × 4.54 × 1.54 inches

Weight

377g / 0.83lbs (excluding batteries)
