Ürün formu

SC207 All Black (Single)

41,730.29TLKDV dahil

Eve Audio SC207 All Black (Single) 150W 7" 2-Way Near & Mid Field Active Studio Monitor (Single)   The best... Devamını oku Devamını oku

Ürün Kodu: 18169
Barkod: 2784000037


4 ürünler Stokta Show extra info for delivery time


Açıklama

Eve Audio SC207 All Black (Single)
150W 7" 2-Way Near & Mid Field Active Studio Monitor (Single)



The best solution among all professional 2-way monitors, providing very high resolution, excellent balance and minimum ear fatigue.

The SC207 is our mid-range two-way monitor speaker and its form factor makes it suitable for many different rooms.
The SC207 has excellent power efficiency, allowing you to clearly examine what's happening in your music. The SC207's modest and elegant size, combined with its quality precision, will ensure your setup looks great without disrupting your workspace.


The SC207 is one of the medium-sized EVE Audio monitors. The SC207 is a monitor that can have a wide range of users and is suitable for use in many different rooms thanks to its size and features.

Are you an amateur musician? No problem. The SC207 has the power and resolution to let you easily examine what’s going on in your music. Are you a post-production professional working in a cramped or relatively small room? No problem either. Its convenient size and satisfying features make the SC207 a sound monitor that will fit easily into your setup, along with its quality precision.

Whatever you do, the SC207 will be with you.

With the SC207, you have a bass frequency range that goes down to 44Hz. This is achieved thanks to the 6.5" honeycomb driver and the 1.5" diameter voice coil, which creates tight, dynamic and more linear vibrations resulting in bass frequencies.

The protective limiting circuit of the PWM amplifier ensures that the speaker will deliver 100W of efficient power for many years, while the maximum level of 106dB SPL at 1m distance allows you to make critical and sharp decisions about your mixes with ease.

The SC207 also uses Eve Audio's proprietary AMT (Air Motion Transformer) RS2 tweeter, which features a large magnet system that allows it to reach higher sound levels.


Bass Port Design
It’s all in the geometry. One of the negative effects of port compression is bass distortion. As you turn up the volume, the efficiency of the port decreases and distortion increases. For our bass port designs, we chose a large rear rectangular port with no hard edges. This is one of the reasons why EVE monitors have high efficiency at low frequencies. The results? High sound pressures with tight, punchy bass frequencies without port distortion. Turn up the volume and EVE will give you the best bass.

Measurements
Free field frequency response (1/6 oct.)
Top = Vertical configuration / Bottom = Horizontal configuration
Red = 0° / Green = 30° off-axis



Corruption
Orange = 2nd / Green = 3rd and frequency response (red)


Polar pattern (1m)
Top = Vertical configuration / Bottom = Horizontal configuration
Red = 200Hz / Green = 1kHz / Blue = 5kHz



Explanation
• Free field frequency range (-3dB): 44Hz - 21kHz
• Tweeter: AMT RS2
• Woofer: 165mm / 6.5"
• Crossover frequency: 2800Hz
• Max SPL at 1m: 116dB
• Number of amplifiers: 2
• Output power (woofer): 100W
• Output power (tweeter): 50W
• Protection limiter: Yes
Settings
• Sound: -inf. - + 6dB
• High-shelf filter (-5dB - + 3dB): > 3kHz
• Desktop filter boost (0dB - + 3dB): 80Hz
• Desktop filter cut-off (-5dB - 0dB): 170Hz
• Low-shelf filter (-5dB - + 3dB): <300Hz
• LED brightness adjustment: Yes
• Level lock dip switch: Yes
• Filter lock dip switch: Yes
Connectors
• XLR input (impedance): (10k)
• RCA input (impedance): (10k)
Power consumption
• Standby: <1W
• Full output: 120VA
Dimensions and weight
• Dimensions (WxHxD) [mm]: 215 x 330 x 280
• Dimensions (WxHxD) ["]: 8.46 x 12.99 x 11.02
• Weight [kg / lb.]: 8 / 17.6
