• 4x Audient Console Microphone Preamps
• Leading Converters in Their Field
• 2x JFET Instrument Input
• Independent Headphone and Stereo Outputs
• Fully Balanced Inputs
• 2x Digital Input & Output

Audient Console Microphone Preamps
The professional sound you deserve
Every iD sound card features the Audient Console Microphone Preamp, the same circuit design found in our renowned recording console, the ASP8024-HE. Designed to deliver ultra-low noise and low distortion with a touch of classic analog warmth, the iD44's four Audient Console Preamps will give you the professional sound you deserve.

How does that sound?
Audient Console Microphone Preamps are a high-quality hybrid discrete and op amp design that delivers a clean, accurate, and detailed translation of your source.

If you would like to learn more about the design of Audient Console Microphone Preamps, you can visit the link below.

Even better ADC performance. Just when we thought we couldn't make the original iD44 sound any better, the MKII sees a huge 9dB improvement in the ADC's THD+N figure, meaning cleaner sound with less noise and less audible distortion.

Expand with ADAT!
More channels, more possibilities
Easily configure your studio to handle larger sessions. Equipped with two optical input and output connectors, the iD44 gives you plenty of options for expansion. Supporting both ADAT and SPDIF, add up to 16 channels of mic preamps to your setup and boost your inputs and outputs.

Balanced Inputs
Hardware Integration
Integrate your favorite outboard FX before converting and start creating signal chains that rival the best. The insert return also provides direct access to the A/D converters, providing the cleanest possible signal path, making it great for integrating print backs or outboard level sources.

• Record with Hardware FX
• Mix with Hardware FX
• Record external microphone preamps
• Bypass internal mic preamps
• JFET Instrument Inputs

Plug and play!
Designed to replicate the input stage of a classic valve amplifier, the iD44 features two harmonically rich JFET Instrument Inputs that provide the perfect sonic foundation for your guitars or basses before they reach your amp simulators.

Speaker Outputs
Connect and listen to your mixes through two sets of speakers with the iD44's four line outputs. Alternatively, use the extra line outputs to send audio to an external headphone amplifier for distribution to your artists.

Headphone Outputs
Easily record and collaborate with others using the iD44's dual stereo headphone amplifiers! Both provide plenty of power to keep your headphones performing properly.

Lost your headphone adapter? Or need a third headphone? iD44 now benefits from the addition of dual headphone outputs, including both a ¼” jack and mini jack for headphone output, providing even greater monitoring flexibility when you need it.

Loopback
We remove the limits of your creativity!
Now equipped with Audio Loop-back, the iD44 can quickly become a multi-purpose powerhouse. Giving you the ability to capture playback from multiple applications on your computer simultaneously with your microphones, Audio Loop-back lets you create a custom audio feed ready to be sent to your streaming software. Ideal for content creators, podcasters and broadcasters.

• Record your computer's audio
• Send audio to live streams
• Collaborate on online mixes
• Record game audio

Audio loop-back is becoming an increasingly in-demand feature due to the rise of podcasting, YouTube/content creators, and game streamers. Check out our comprehensive guide to Audio Loop-back.

---

Mixer Software
Experience ultra-low latency
The iD mixer tightly integrates hardware and software, allowing you to effortlessly set up low-latency direct monitoring, create up to four stereo artist cue mixes, name and customize channels, save layout presets, assign hardware function buttons, and quickly set up advanced routing. The iD44’s Loopback feature is also controlled via the Software Mixer, allowing you to select the Loopback source from 6 different options to suit a variety of practical scenarios. Endless possibilities, fast workflow.

Talkback
Innovation meets communication
iD44's exclusive talkback technology lets you use any audio source connected to your computer, such as the built-in microphone or a USB microphone, as your talkback microphone, freeing up valuable microphone preamps for recording.

Made for music
Reliable performance, a simple layout, and a highly intuitive user experience let you focus on what you do best: making music. We can't wait to hear what you create.

Console Style Monitor Control
Work faster
Speed ​​up your workflow with iD44's three programmable function buttons. Assign any of the advanced monitoring features, including Speaker Select, Mono Sum, Polarity Reverse, or Cue Mix monitoring, to the F buttons and quickly take control of your session.

Scroll Control
Virtual scroll wheel
Turn iD44's volume knob into a virtual scroll wheel and take control of a variety of compatible on-screen parameters. Quickly dial in settings, adjust faders, and even write automation without spending hours staring at the screen.

All Metal Construction
In perfect health!
With its all-metal construction, hand-machined aluminum knobs, and high-quality component selection, the iD44 delivers professional-quality sound in a beautifully designed and simple package.

Produce instantly!
Bundled with industry-leading plug-ins and virtual instruments, plus a free suite of creative software including Cubase LE and Cubasis LE for iOS, you can start recording right out of the box.

Features
Microphone preamplifier
• MICROPHONE: 0 to +60 dB
• LINE: -10 to +50dB
• PHANTOM POWER: 48v +/-4v @ 10mA/Channel (12VDC only)
• MIC AUDIO: -126dBu
• CMRR: >80dB @ 1kHz
• MAXIMUM INPUT LEVEL: +18 dBu
• INPUT IMPEDANCE (Mic): 3k Ω balanced
• INPUT IMPEDANCE (Line): 10k Ω balanced
• FREQUENCY RESPONSE: ±0.5 dB 10Hz - 65kHz
• CROSS: <-90 dBu @ 1kHz & 10kHz
• THD+N @ 0dBu (1kHz): 0.003% (-96dBu)
• SNR: 96dB
• XLR: Pin 2 (Hot), Pin 3 (Cold) and Pin 1 (Shield)
• 1/4” TRS JACK: TIP (Hot), RING (Cold) & HANDLE (Shield)

DI / Device Input (Channel 1):
• DI GAIN: 0 to +60 dB
• MAXIMUM INPUT LEVEL: +10dBu
• INPUT IMPEDANCE: 1MegΩ Unbalanced
• FREQUENCY RESPONSE: ±0.5 dB 10Hz - 50kHz
• THD+N @ 0dBu (1kHz): <0.3%
• SNR: 95dB A-weighted
• 1/4” JACK: Tip (Hot) and Sleeve (Shield)

Analog to Digital Converter (ADC 1 and 2):
(Measured with Insert Return under AES-17)
• MAXIMUM INPUT LEVEL: +18 dBu (0 dBFS digital maximum)
• DIGITAL REFERENCE LEVEL: +18 dBu = 0 dBFS
• INPUT IMPEDANCE: >10k Ω Balanced
• CROSS: -115 dBu @ 1kHz & 10kHz
• FREQUENCY RESPONSE: ±0.5 dB 10Hz - Fs/2 (Nyquist)
• CROSS: -115dBu @ 1kHz and 10kHz
• THD+N @ -1dBFS (1kHz): <0.0003% (-112dB)
• DYNAMIC RANGE: 120 dB A-weighted
• 1/4” TRS JACK: TIP (Hot), RING (Cold) & HANDLE (Shield)

Digital to Analog Converter (DAC 1 and 2):
(Measured under AES-17 on line outputs 1 and 2)
• MAXIMUM INPUT LEVEL: +18 dBu (0 dBFS digital maximum)
• DIGITAL REFERENCE LEVEL: +18 dBu = 0 dBFS
• OUTPUT IMPEDANCE: <100 Ω
• CROSS: <-118 dBu @ 1kHz and 10kHz
• FREQUENCY RESPONSE: ±0.5 dB 10Hz - Fs/2 (Nyquist)
• CROSS: -115dBu @ 1kHz and 10kHz
• THD+N @ -1dBFS (1kHz): <0.0006% (-104dB)
• DYNAMIC RANGE: 124 dB unweighted, 126 dB A-weighted
• 1/4” TRS JACK: TIP (Hot), RING (Cold) & HANDLE (Shield)

Headphone Outputs:
(Measured under AES-17 at headphone output)
• MAXIMUM OUTPUT LEVEL: +14 dBu (0 dBFS digital maximum)
• DIGITAL REFERENCE LEVEL: +14 dBu = 0 dBFS
• OUTPUT IMPEDANCE: <50 Ω unbalanced
• CROSS: <-110 dBu @ 1kHz and 10kHz
• FREQUENCY RESPONSE: ±0.5dB 10Hz - Fs/2
• CROSS: -115dBu @ 1kHz and 10kHz
• THD+N @ -1dBFS (1kHz): <0.0008% (-103 dB)
• DYNAMIC RANGE: 121 dB unweighted, 124 dB A-weighted
• MAX LEVEL into 30ohm: +10.2dBu 0.002% THD+N Power: 210mW
• MAX LEVEL IN 60ohm: +14.2dBu 0.001% THD+N Power: 54mW
• MAX LEVEL IN 600ohm: +14.2dBu 0.001% THD+N Power: 54mW
• 1/4” JACK: TIP (Hot), RING (Cold) & HANDLE (Shield)

USB2.0 High Speed:
• NUMBER OF INPUT CHANNELS 20: 20 (4 Analog, 16 Digital)
• NUMBER OF OUTPUT CHANNELS 24: 24 (8 Analog, 16 Digital)
• Connector: USB Type-C
• Included Cables: 1.5m USB 2.0 Type-C to USB Type-C, 1.5m USB 2.0 Type-C to USB Type-A

DSP Mixer Latency – ROUND TRIP (in-to-out):
• 44.1kHz 0.677ms
• 48.0kHz 0.625ms
• 88.2kHz 0.354ms
• 96.0kHz 0.323ms

Dimensions:
• Unit: 276 mm (w) x 51 mm (h) x 174 mm (d)
