2408mk3 Core
79,734.61TLKDV dahil
2 ürünler Stokta Show extra info for delivery time
Açıklama
Motu 2408mk3 Core
Versatile Hard Disk Recording System: 3x ADAT-TDIF I/O, 8x ANALOG I/O, SP/DIF I/O, Word Clock I/O, PCI-424

OVERVIEW
This box has all the features you need to turn your computer into a powerful 24bit/96kHz digital audio station. The 2408MK3 is an audio interface that provides 8 channels of high quality analog recording and playback, as well as 24 channels of ADAT and Tascam digital I/O options in a single rack system. Up to 4 units of 2408MK3 can be connected to the PCI-424 card, providing you with 96 channels of independent 96kHz resolution input and output.
The 2408MK3 is ideal for computer-based recording in project studios without a mixing desk or in any professional studio with a digital mixer of any size.
The 2408MK3 provides cross-platform compatibility with all your favorite audio application programs based on Windows 98SE/ME/2K/XP and/or Macintosh, while also offering 24-bit recording/editing/mastering capabilities with the Macintosh-based AudioDesk workstation software.
CueMix DSP™
The PCI-24 card includes CuemixDSP™, a very powerful processor for creating personalized mixes with 96kHz sound quality on 96 channels. Since the mixing is done on the card itself, it can be done with zero latency like today's digital mixers, without having to go from the PCI bus to the server processor.

CuemixDSP™ is the most flexible Cuemix you can use. It lets you mix multiple channels, multiple mix buses, or directly to dedicated outputs.
The Cuemix console features independent level pan controls for each of your inputs. It also doesn't limit you to just 4 stereo mixes. It gives you unique mix settings for each of your physical stereo outputs. This means you can have up to 48 separate stereo mixes in a 96-output system.
MDM Connection
MDM Connection
2408mk3 also works as a stand-alone audio format converter. You can convert any audio format you want to any audio format in the 8 channel bank.

If you expand your 2408mk3 system to 4 2408mk3 I/O rack units, you can connect 96 channels of ADAT optics and 96 channels of TASCAM TDIF simultaneously, then transfer 96 channels of material in a single pass.
S/PDIF
The 2408mk3 provides S/PDIF digital inputs and outputs. This allows you to exchange digital sounds with this industry-standard format. However, the 2408mk3 takes S/PDIF one step further by providing an additional S/PDIF stereo output for your main mix. You can use this extra input however you want. For example, you can keep a DAT machine connected at all times and record your project whenever you want, without having to change cables.

SMPTE and Word Clock
The 2408mk3 is the first audio interface to feature video and SMPTE time code matching. This feature allows you to use the 2408mk3 as a slave for video, SMPTE, or both without a dedicated synchronizer.

Technical Specifications
• 8 analog inputs/outputs with 24-bit, 96kHz converters, balanced/unbalanced ¼” TRS connections
• 108dB S/N ratio (A-weighted)
• 24 channel ADAT optical input/output
• 24 channel TDIF (Tascam digital) input/output
• 2 channel S/PDIF input and 4 channel output
• 16, 20 and 24-bit recording @ 44.1, 48, 88.2 and 96 kHz
• ADAT sync input via PCI-424 card
• Word clock input and output
• Ability to work in multiple systems with a PCIX-424 or PCIe-424 card
• Chassis size, excluding connectors, front and rear buttons and rack ears: 48.26 × 17.78 × 4.45 cm
• Full system requirements: PCIX-424 card, PCIe-424 card
